Rotary Screen
- Product details
A trommel screen, also known as a rotary screen, is a mechanical screening machine used to separate materials, mainly in the mineral and solid-waste processing industries. It consists of a perforated cylindrical drum that is normally elevated at an angle at the feed end. Physical size separation is achieved as the feed material spirals down the rotating drum, where the undersized material smaller than the screen apertures passes through the screen, while the oversized material exits at the other end of the drum.
Scope: waste metal, municipal solid waste, construction waste and so on.
Parameters：
Model | GTS1500 | GTS2500 | GTS2500 |
Power（kW） | 5.5 | 22 | 15 |
Screen diameter（mm） | ∅120 | ∅20, ∅40, ∅60, ∅80 | ∅20, ∅40, ∅60, ∅80 |
Weight（t） | 8.3 | 38 | 34 |
Processing capacity（t/h） | 15 | 45 | 15 |
